Key Specifications / Features
Model No.: LF-20260422-WNF-01 Hits: 0
The plant produces forged weld neck flanges to ASME B16.5 specifications. These 12-inch (DN300) WN flanges are forged from normalized ASTM A105N carbon steel and rated for Class 600 LB (PN100) high-pressure service. They feature SCH 80 wall thickness for enhanced structural integrity and a tapered hub that transitions smoothly into the pipe wall. The integral weld neck design provides superior fatigue resistance and stress distribution.
Tags:
Detail Information
Product Name: Forged Weld Neck Flanges
Type: Weld Neck Flange
Design Standard: ASME B16.5
Material: ASTM A105N, Forged Carbon Steel
Size: 12 Inch, DN300
Pressure Rating: Class 600 LB, PN100
Wall Thickness: SCH 80
Surface Treatment: Black Painting
Type: Weld Neck Flange
Design Standard: ASME B16.5
Material: ASTM A105N, Forged Carbon Steel
Size: 12 Inch, DN300
Pressure Rating: Class 600 LB, PN100
Wall Thickness: SCH 80
Surface Treatment: Black Painting
